LTM M 232 CNG cylinder hot spinning machine (Template)

Diameter: DN200~232mm

Length: 700~1700mm

Thickness: 3~15mm

Main power: 37KW

Central height: 1000mm

Control method: PLC

Category:

Description

Tube OD: Max.232mm

Tube OD: Min.200mm

Tube thickness: Max.15mm

Tube thickness: Min.3mm

Initial running length: Max.1700mm

Initial running length: Min.700mm

Central height: 1000mm

Main engine power: 37KW

Template rotation angle:90°

Template central height adjustment: ±20mm

Control methods: PLC

Machine dimension: 16000 x 2000 x 1300mm

Heating type:Single-hole induction heating





No.ItemQty  (set)

Remark

1

LTM M 232 hot spinning machine

11. Material unloading device

2. Material reverse device

3. Main engine

4. Mould device

5. Conveyor device

6. Lubrication device

7. Hydraulic device

8. Control system

2

Mid-frequency heating induction furnace

1

1. Medium frequency power supply;

2. Single-hole heating furnace

3. With insulation protection inductance

3

Auto steel pipe heating device

1

1. Material splitting device

2. Auto. heating mechanical arm

3. Steel pipe rotation heating device

4. Material feeding frame

5. Material dialing device



Finished sample
